Manufacturer's code:
10062388Tester of battery brand
MSW provides quick and legible measurements. Using a handy device, you can check the batteries
12 V and
24 V The device is operated with just a few buttons. Additionally, the battery meter is protected against short circuit and wrong polarization. The meter provides a fast, clear and accurate result in just
5 secondsThe values are automatically saved and compared. The meter checks: the state of charge (SOC), the possibility of cold start (CCA), voltage, internal resistance, charging systems and start-up. The tester checks the state of the battery by means of modern conduction measurement, not as in conventional methods, in which the battery is unloaded by using a load resistor. The digital battery meter emits a series of voltage pulses and measures the flow of the current flow in response. This gives fast and reliable information about the remaining battery capacity and performance. The device has SAE, CCA, BCI, DIN, EN, IEC, GB, CA/MCA and JIS. The battery tester has 2 quick functions. One press the key is passed to the voltmeter and a quick test. The battery meter also displays results in English, German, Spanish, French, Dutch and Italian.
Product features: - - Testing 12 V and 24 V batteries from cars, motorcycles or scooters,
- - The test with all results is performed in only 5 seconds,
- - Safely measures the capacity from 40 to 200 Ah,
- - Comfortable, readable LCD display and simple operation with several buttons,
- - The protective function prevents damage caused by short circuit and mispolarisation.
Technical parameters: - - Catalog number - 10062388
- - The state of the article - New
- - Model - MSW-BLT-2
- - Material - ABS, PVC, PC, Nickel plated iron, Silicon gel
- - Cold start (CCA) - 100-2000
- - Range DIN - 100-1400
- - Scope EN - 100-2000
- - IEC range - 100-1400
- - Maximum voltage value [V] - 30
- - Display - LCD
- - Optional battery standards - CCA / BCI / CA / MCA / EN / SAE / IEC / DIN / JIS / GB
- - Battery Ageing (SoH) - 0-100%
- - Voltage range [V] - 8-30
- - Duration of the test - Ok. 5 s to the result
- - Load status (SoC) - 0-100%
- - Dimensions (DxSxW) - 7.5 x 2 x 15 cm
- - Weight - 0.25 kg
- - Dimensions of shipment (DxSxW) - 11 x 17 x 5.5 cm
- - Weight of dispatch - 0.3 kg
Included:
